voyah free ev

$ 32,667

Voyah FREE pure electric version
2022 DNA 475km four-wheel drive pure electric version
2022 631km four-wheel drive ultra-long range version

Basic parameters
Manufacturer’s guide price 419,900 393,600
Manufacturer Lantu Automobile Lantu Automobile
time to market 2022-08-26 2022-09-15
level Medium and large SUV Medium and large SUV
Body structure SUV SUV
Energy type pure electricity pure electricity
Motor[Ps] 694 490
gearbox 1st gear fixed gear ratio 1st gear fixed gear ratio
Length*width*height[mm] 4910*1950*1660 4905*1950*1645
CLTC pure electric range [km] – 631
WLTC pure electric range [km] – –
NEDC pure electric range [km] 475 –
Official 0-50km/h acceleration [s]
Official 0-100km/h acceleration [s] 4.7 4.4
Maximum speed [km/h] 200 200
Vehicle warranty 5 years or 100,000 kilometers 5 years or 100,000 kilometers
First owner warranty policy – –
Exterior color
interior color

Body
Length[mm]
Width[mm]
Height[mm]
Wheelbase [mm] 2960 2960
Front wheelbase [mm] 1654 1654
Rear wheelbase [mm] 1647 1647
Minimum ground clearance without load [mm] 163 163
Minimum turning radius [m]
Number of doors 5 5
number of seats 5 5
Approach angle [°] – –
Departure angle[°] – –
Passage angle [°]
Minimum ground clearance with full load [mm]
Drag coefficient [Cd]
Car door opening method
Front trunk volume [L] 72 72
Trunk volume [L] 560-1320 560-1320
Curb weight [kg] 2330 2310
Full load mass [kg] 2705 2705

engine

electric motor
Motor brand
Motor model
Number of drive motors Dual motor Dual motor
Motor layout Front + rear Front + rear
Motor type Communicate asynchronously Communicate asynchronously
Total motor power [kW] 510 360
Total motor horsepower [Ps] 694 490
Motor total torque [N·m] 1040 720
Maximum power of front electric motor [kW] 255 –
Maximum torque of front electric motor [N·m] 520 –
Maximum power of rear electric motor [kW] 255 –
Maximum torque of rear electric motor [N·m] 520 –

Battery
Battery Type Ternary lithium battery Ternary lithium battery
Battery brand
Battery temperature management ● ●
Battery power [kWh] 88 106
Battery energy density [Wh/kg] – –
Electricity consumption per 100 kilometers [kWh/100km] 19 19
vehicle charging port ●Slow charging port ●Fast charging port ●Slow charging port ●Fast charging port
Slow charging port location
Fast charging port location
High voltage fast charging platform
Fast charging power [kW] – –
Fast charging time[min]
Fast charging time[h] 0.75 0.75
Fast charging capacity [%] 20-80 20-80
Slow charging power [kW] – –
Slow charging time[h] 8.5 10
Slow charging capacity [%] 20-100 20-100
Vehicle battery swap – –
Home charging pile – –
Car charging gun – –
External discharge function
External discharge power
Battery pack warranty 8 years or 120,000 kilometers 8 years or 120,000 kilometers
First owner battery pack warranty – –

gearbox
Gearbox type Fixed gear ratio Fixed gear ratio
Gearbox description Electric vehicle single speed gearbox Electric vehicle single speed gearbox
Number of gears 1 1

chassis steering
Drive form Dual motor four-wheel drive Dual motor four-wheel drive
four-wheel drive
Center differential structure – –
Front suspension type Double wishbone independent suspension Double wishbone independent suspension
rear suspension type Multi-link independent suspension Multi-link independent suspension
Assist type electric assist electric assist
Adjustable suspension features ●Height adjustment ●Hard and soft adjustment ●Height adjustment ●Hard and soft adjustment
Adjustable suspension types ●Air suspension ●Air suspension
Body structure Load-bearing Load-bearing
limited slip differential – –
Differential lock – –
Maximum wading depth[mm]

wheel brake
Front brake type ●Ventilated disc type ●Ventilated disc type
rear brake type ●Ventilated disc type ●Ventilated disc type
Parking brake type Electronic parking Electronic parking
Front tire specifications 255/45 R20 255/45 R20
Rear tire specifications 255/45 R20 255/45 R20
Spare tire ●No spare tire ●No spare tire
Spare tire placement – –

active safety
ABS anti-lock ● ●
Braking force distribution (EBD/CBC, etc.) ● ●
Brake assist (BA/EBA/BAS, etc.) ● ●
Traction control (ASR/TCS/TRC, etc.) ● ●
Body stability control (ESP/DSC/VSC, etc.) ● ●
Tire pressure monitoring ●Tire pressure display ●Tire pressure display
Seat belt not fastened reminder ●The whole car ●The whole car
In-car biometric monitoring

passive safety
Main driver airbag ● ●
Passenger airbag ● ●
First row side airbag ● ●
Second row side airbags – –
side curtain airbags ● ●
knee air bag – –
Passenger seat cushion airbag – –
Rear seat belt airbag – –
Rear seat anti-skid airbags – –
center airbag – –
Second row forward airbags – –
child seat interface ● ●
passive pedestrian protection – –
Run-flat tires – –

Auxiliary/control configuration
front parking radar ● ●
Rear parking radar ● ●
Reverse side warning system ● ●
Door opening collision warning
Driving assistance images ●360-degree panoramic image ●180-degree chassis perspective ●360-degree panoramic image ●180-degree chassis perspective
Chassis perspective
cruise system ●Full-speed adaptive cruise ●Full-speed adaptive cruise
Driving mode selection ●Sport ●Economy ●Standard/Comfortable ●Off-road ●Sport ●Economy ●Standard/Comfortable ●Off-road
Fatigue reminder ● ●
automatic parking ● ●
remote control parking – –
remote summoning
automatic parking ● ●
Hill assist ● ●
steep descent ● ●
night vision system ● ●
variable steering ratio – –
Integral active steering system – –
Wading sensor system – –
low speed four wheel drive
creep mode
tank turns

Assisted driving functions
Anti-rollover system
Parallel assistance (BSM/BSD) ● ●
Lane Departure Warning (LDWS) ● ●
Lane Keeping (LKAS) ● ●
Lane centering
Road traffic sign recognition ● ●
forward collision warning
rear collision warning
Active braking ● ●
Automatic lane change assist – –
Automatic ramp exit/entry – –
Reverse tracking – –
High-speed assisted driving
Urban assisted driving

Assisted driving hardware
Driving assistance level Driving assistance (L2) Driving assistance (L2)
Assisted driving system – –
Assisted driving chip – –
Chip computing power – –
Environment aware camera – –
Environment sensing camera pixels [10,000]
Front sensing camera type Binocular Binocular
Front sensing camera pixels [10,000]
surround camera 4 4
Surround camera pixels [10,000]
car camera 2 2
ultrasonic radar First 6/Last 6 First 6/Last 6
millimeter wave radar 3 3
lidar – –

External configuration
Skylight type ●The panoramic sunroof cannot be opened ●The panoramic sunroof cannot be opened
Light-sensing awning
Sport appearance package – –
Electric spoiler – –
Rim material ●Aluminum alloy ●Aluminum alloy
Electric suction door – –
Automatic opening and closing of car doors – –
Frameless door – –
sliding door – –
roof rack ● ●
Key type ●Remote key ●Bluetooth key ●Remote key ●Bluetooth key
Keyless start ● ●
keyless entry ●The whole car ●The whole car
Hidden electric door handle ● ●
Active closing air intake grille – –
Electric tailgate ●Electric opening and closing ●Inductive opening and closing ●Position memory ●Electric opening and closing ●Inductive opening and closing ●Position memory
Tailgate position memory
Induction tailgate
Tailgate glass opens independently – –
car side pedals – –
Low speed driving warning sound ● ●
Sentinel (clairvoyance) mode ● ●
tow hook
Trailer power outlet
Induction tailgate

Internal configuration
Steering wheel material ●Leather ●Leather
Multifunction steering wheel ● ●
Shift pattern
steering wheel adjustment ●Manual up and down + front and rear adjustment ●Manual up and down + front and rear adjustment
Steering wheel heating – –
Trip computer display ●Color ●Color
Full LCD instrument panel ● ●
Instrument screen size ●12.3 ●12.3
Instrument screen material
Instrument screen resolution [px]
Instrument screen pixel density [PPI]
HUD heads up display – –
Built-in driving recorder ● ●
Mobile phone wireless charging ●First row ●First row
Maximum wireless charging power of mobile phones [W]
steering wheel gear shift – –
ETC device
Active noise reduction – –
Single pedal mode – –
Electrically adjustable pedals – –

Seat configuration
seat material ●Leather/fleece material mix and match ●Leather/fleece material mix and match
Sports style seats – –
Electric driver’s seat adjustment ●Electric adjustment with memory ●Electric adjustment with memory
Passenger seat electric adjustment ●Electric adjustment ●Electric adjustment
Driver’s seat adjustment method ●Front and back adjustment ●Backrest adjustment ●Height adjustment (4-way) ●Waist adjustment (4-way) ●Front and back adjustment ●Backrest adjustment ●Height adjustment (4-way) ●Waist adjustment (4-way)
Passenger seat adjustment method ●Front and back adjustment ●Backrest adjustment ●Height adjustment (4-way) ●Waist adjustment (4-way) ●Front and back adjustment ●Backrest adjustment ●Height adjustment (4-way) ●Waist adjustment (4-way)
First row seat functions ●Heating ●Ventilation ●Massage ●Heating ●Ventilation ●Massage
Boss button – –
Electrically adjustable second row seats – –
Second row seat adjustment method – –
Second row seat functions – –
Electrically adjustable third row seats
Third row seat adjustment method
Third row seat functions
Electric footrest
Zero Gravity Seat Function
center armrest ●First row ●Second row ●First row ●Second row
Seat layout – –
Rear seat folding method ●Inverted proportions ●Inverted proportions
Rear cup holder ●Second row ●Second row
Electrically reclining rear seats – –
Rear folding table – –
Heated/cooled cup holder – –

Multimedia configuration
Central control color screen ●Touch LCD screen ●Touch LCD screen
Central control screen size ●12.3 ●12.3
Screen size under central control – –
Central control screen material
Central control screen resolution [px]
Central control screen pixel density [PPI]
Passenger screen ●Touch LCD screen ●Touch LCD screen
Passenger screen size ●12.3 ●12.3
Vehicle system
Passenger screen material
Passenger screen pixel density [PPI]
Car chip Qualcomm Snapdragon 8155 –
Vehicle system memory (GB)
Vehicle system storage (GB)
satellite navigation system ● ●
Navigation traffic information display ● ●
AR real-life navigation
Car navigation map ●Baidu ●Baidu
HD map
V2X communication
roadside assistance call – –
Vehicle-to-machine network ●5G ●5G
Car WiFi function ●WiFi connection ●WiFi hotspot ●WiFi connection ●WiFi hotspot
OTA upgrade ●Vehicle OTA ●Vehicle OTA
Car APP application market ● ●
Voice recognition control function ●Multimedia system ●Navigation ●Telephone ●Air conditioning ●Sunroof ●Multimedia system ●Navigation ●Telephone ●Air conditioning ●Sunroof
Voice zone wake-up
Voice wake-up-free
Speech continuous recognition
Mobile phone interconnection/mapping ●Support HiCar ●Support HiCar
Voice assistant wake word ●Hi, Lantu ●Hi, Lantu
gesture control ● ●
face recognition
Remote control function ●Remote unlocking ●Remote ventilation ●Remote starting ●Remote unlocking ●Remote ventilation ●Remote starting
Car CD/DVD – –
Split screen function – –
Multimedia/charging interface ●USB●Type-C ●USB●Type-C
Bluetooth/car phone ● ●
Number of USB/Type-C interfaces ●2 in the front row/2 in the back row ●2 in the front row/2 in the back row
In-car entertainment functions – –
simulated sound
Rear seat control multimedia – –
audio brand ●Dynaudio Dynaudio ●Dynaudio Dynaudio
Luggage compartment power interface ●12V ●12V
Number of speakers ●10 ●10
Rear multimedia screen – –
Cockpit 220V/230V power supply – –

Lighting configuration
Low beam light source ●LED ●LED
high beam light source ●LED ●LED
Lighting features ●Matrix ●Matrix
LED daytime running lights ● ●
Headlight function ●Height adjustment ●Automatic opening and closing ●Adaptive high and low beams ●Delayed shutdown ●Height adjustment ●Automatic opening and closing ●Adaptive high and low beams ●Delayed shutdown
Turn assist light – –
Front fog lights – –
Headlight cleaning device – –
Car interior ambient light ●Multicolor ●Multicolor
Rear multimedia screen size
Rear multimedia screen material
Rear multimedia screen resolution [px]
Rear multimedia screen pixel density [PPI]

glass/rear view mirror
First row electric windows ● ●
Second row power windows ● ●
One-click lifting and lowering of windows ●The whole car ●The whole car
Window anti-pinch function ●The whole car ●The whole car
Multilayer soundproof glass ●First row ●First row
Exterior rearview mirror function ●Electric adjustment ●Heated rearview mirrors ●Electric folding ●Mirror memory ●Automatically flip down when reversing ●Automatically fold when the car is locked ●Electric adjustment ●Heated rearview mirrors ●Electric folding ●Mirror memory ●Automatically flip down when reversing ●Automatically fold when the car is locked
Interior rearview mirror function ●Automatic anti-dazzle ●Automatic anti-dazzle
Rear side privacy glass ● ●
Rear side sunshades – –
Rear windshield sunshade – –
Car vanity mirror ●Main driver ●Co-pilot ●Main driver ●Co-pilot
Sensing wiper function ●Rain sensor type ●Rain sensor type
rear wiper ● ●
Heated water nozzle – –

Air conditioning/refrigeration
First row air conditioner ●Dual-temperature zone automatic air conditioning ●Dual-temperature zone automatic air conditioning
Second row air conditioner ●Air outlet ●Air outlet
Third row air conditioner – –
heat pump air conditioner
air quality monitoring
In-car PM2.5 filter device ● ●
Car air purifier ● ●
negative ion generator – –
Fragrance system ● ●
car refrigerator – –
body type

suv
body type level

middle and large
brand

voyah
fuel type

EV

Video

相关产品

Contact
  • +86 15102761875
  • chris@cnautozone.cn
  • No. 138, Guangma Avenue, Mayong Town, Dongguan City, Guangdong Province
  • No. 8-1, Shinan Avenue, Huangge Town, Nansha District, Guangzhou City, Guangdong Province
Company Links
send a message
Location
滚动至顶部
